Double-head automatic feeding slab plastic molding machine use:
This machine is mainly suitable for vacuum plastic forming of various plastic products such as ABS, PP, PS, PVC, EPS, HIPS and other thermoplastic thick sheets...
Double-head automatic feeding slab plastic molding machine use:
This machine is mainly suitable for vacuum plastic forming of various plastic products such as ABS, PP, PS, PVC, EPS, HIPS and other thermoplastic thick sheets. It can be manufactured in the corresponding mold: car and boat trim, household appliance liner, door panel, lighting, luggage, decorative parts, furniture, sanitary ware, lamps, toys, teaching equipment, art advertisements, traffic signs, tray liners, etc. product. (This aircraft mainly adapts in ABS, PP, PS, PVC, EPS)
Thick sheet double-head automatic feeding and forming machine features: (Characteristic)
The heater uses a new far-infrared heating element, which automatically controls temperature, heats evenly, and consumes low energy.
Digital 1000-speed temperature control: 1 thousand gear position adjustment, 1000 digital furnace temperature control, full-time constant power with voltage compensation, when the voltage fluctuation is within 20%, the error is compensated ±1% to solve the voltage fluctuation can make the furnace The temperature remains stable for a long time.
Thick sheet double-head automatic feeding plastic forming machine technical parameters:
| Model | JY-760DB |
| Forming Area | L 510-1500mm W520-700mm |
| Specifications sheet | 1560×760mm |
| Sheet thickness | 3mm |
| Forming the largest high | 500mm |
| Machinery size | 4000*1400*3100mm |
| Work efficiency | 1-4次/min (depending on the thickness and softening of the sheet) |
| Power | 380/220V50Hz (three-phase four-wire system) |
| Air Consumption | (external air supply) ≥ 2 cubic meters / minute |
| Power | (maximum) 56KW |
| Work pressure | (air source pressure) 0.6Mpa (air source 0.8-1Mpa) |
