Multi-arc ion plating has the characteristics of high film density, strong adhesion and fast deposition speed.
Multi-arc ion plating has the characteristics of high film density, strong adhesion and fast deposition speed.
Multi-arc ion plating technology can be used to plate wear-resistant films (TiN, TiC, TiALN), anti-corrosion films (such as AL, CR, stainless steel, TiN, etc.), as well as decorative films (imitation gold TiN, ZRN) Such as watch cases, hardware, ceramic decoration, etc.
The new magnetic field design and the arc source structure design are adopted to optimize the magnetic field distribution, greatly improve the stability of the arc source work, greatly reduce the droplets in the film layer, and uniformly etch the cathode surface to improve the target. Utilization.
The large-area multi-arc and columnar magnetic control multi-arc technology is a new technology in China. It absorbs the advantages of foreign multi-arc equipment and has developed a multi-arc magnetic control device specially designed for coating on the spectacle frame. It can be gold-plated on the spectacle frame. Color, black, silver, blue, red, green, colorful and other colors, wear resistance, corrosion resistance and adhesion is significantly better than electrophoretic paint and spray paint.
Multi-arc ion plating has the characteristics of high film density, strong adhesion and fast deposition speed.
Multi-arc ion plating technology can be used to plate wear-resistant films (TiN, TiC, TiALN), anti-corrosion films (such as AL, CR, stainless steel, TiN, etc.), as well as decorative films (imitation gold TiN, ZRN) Such as hand, ceramic glass decoration, case, hardware and so on.
The new magnetic field design and the arc source structure design are adopted to optimize the magnetic field distribution, greatly improve the stability of the arc source work, greatly reduce the droplets in the film layer, and uniformly etch the cathode surface to improve the target. Utilization.
The large-area multi-arc and columnar magnetic control multi-arc technology is a new technology in China. It absorbs the advantages of foreign multi-arc equipment and has developed a multi-arc magnetic control device specially designed for coating on the spectacle frame. It can be gold-plated on the spectacle frame. Color, black, silver, blue, red, green, colorful and other colors, wear resistance, corrosion resistance and adhesion is significantly better than electrophoretic paint and spray paint.
| Equipment model | JYDC-1800 | JYDC-2000 | JYDC-2200 | JYDC-2300 |
| Vacuum chamber size | 1800×2000 | 2000×2200 | 2200×2600 | 2600×3800 |
| Film type | Automatically complete the coating process at one time | |||
| Power Type | High-voltage ion bombardment power supply, thyristor power supply | |||
| Vacuum chamber structure | Vertical horizontal single door, air extraction system | |||
| Vacuum system | Spool valve + Roots pump + diffusion pump + maintenance pump (or optional: cryogenic pump, cryogenic system) | |||
| Protective film gas | Independent stainless steel gas tank AK, BK, CK | |||
| Inflatable system | Three-way solenoid valve (import) for regulating inflation | |||
| High pressure bombardment system | 30KVA 3000V | |||
| Ultimate vacuum | 8×10-4pa (no load, clean room) | |||
| Pumping time | No-load atmosphere is pumped to 5×10-2pa for less than 6 minutes | |||
| Workpiece rotation | 6-axis / 8-axis / 9-axis public rotation / frequency conversion stepless speed regulation | |||
| control method | Manual + semi-automatic + fully automatic integration / touch screen + PLC | |||
| Remarks | The size of the vacuum chamber can be customized according to customer's products and special process requirements. | |||
